All probes can be manufactured in an MRI compatible version


All probes have 5 independent zones (exc T10 & T14). Each zone can be set at a different temperature, ramp and duration
Dual Probes
Driven by One TCS
2 Independant zones on each
For multiple sites stimulations
Best suited for QST
Best suited for small stimulation areas
e.g. intraoral stimulation
Best suited for prolonged
stimulations
&
MRI Research
Best suited for QST
&
Cold/Heat
Evoked Potentials
Best suited for Cold/Heat
Evoked Potentials
&
Thermal Grill Illusion
Best suited for Cold/Heat
Evoked Potentials
Best suited for
Small Area
Stimulations
T 14

Probe Dimensions
(cm)
L / W / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
6.6 x 5.2 x 4.7
3.6 cm2 / probe
7.4 x 12.2 mm
100°C/sec
75°C/sec
T 11

Probe Dimensions
(cm)
L / W / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
6.6 x 4 x 4.4
9 cm2
7.4 x 24.2 mm
100°C/sec
75°C/sec
T 10

Probe Dimensions
(cm)
L / W / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
16 x 0.8
0.25 cm2
5 x 5 mm
150°C/sec
75°C/sec
T 09

Probe Dimensions
(cm)
L / W / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
6.6 x 4 x 4.4
4.5 cm2
7.4 x 12.2 mm
100°C/sec
75°C/sec
T 08

Probe Dimensions
(cm)
L / W / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
6.6 x 4 x 4.4
4.5 cm2
7.5 x 12 mm
170°C/sec
75°C/sec
T 04

Probe Dimensions
(cm)
L / W / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
6.6 x 4 x 4.4
1.6 cm2
3.2 x 9.9 mm
300°C/sec
75°C/sec
T 03

Probe Dimensions
(cm)
Diam / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
4.4 x 10.5
1.2 cm2
3 x 3.2 x 2.4 mm
300°C/sec
75°C/sec
T 01
.jpg)
Probe Dimensions
(cm)
Diam / H
Total stimulation surface
Dimension of each zone
Max Speed
MRI Version Max Speed
2.5 x 10.5
0.4 cm2
3.2 x 2.4 mm
300°C/sec
75°C/sec
